GB 2673 — Sizes, Materials & Prices

208 variants · 11 diameters × 24 lengths in stock

GB 2673 — Sizes, Materials & Prices

GB 2673 as it is supplied across our catalogue.

In stock now: 208 lines; covering Screws (208), Torx Screws (208), GB2673 (208); priced from $0.0080 per piece. Every line is sold by the piece — one piece is a valid order.

Related values on the same axis

Product families covered

Frequently asked

How much do GB 2673 fasteners cost?
Prices in our catalogue for GB 2673 run from $0.0080 to $1.0554 per piece, depending on diameter, length and material. There is no minimum order.
Is there a minimum order quantity for GB 2673?
No. Every line is sold by the piece, so you can order a single piece to check the fit and the finish before committing to a production quantity. Your order total is confirmed in the cart, before payment.
What do you stock in GB 2673?
GB 2673 — Sizes, Materials & Prices currently covers 208 lines across Screws, Torx Screws, GB2673. The full list of sizes, materials and finishes on this page is live — use the filters at the top to narrow it down.
How quickly do you ship GB 2673 fasteners, and can you send them to the EU or Russia?
In-stock lines leave our Foshan warehouse within 24–48 hours. We ship worldwide, including the EU and Russia. For the EU we are appointing a responsible person under Regulation (EU) 2023/988 (GPSR); for EAEU orders the conformity documents are handled with the importing party, who is the applicant of record. We can supply an EN 10204 3.1 mill test certificate, a full technical specification and a packing list with weights on request.
Dimension matrix — all diameters
Sellable sizes — pick a cell to see every surface and finish
D \ L 35 25 30 80 4 50 60 14 16 10 12 8 6 5 40 100 45 18 55 20 70 22 90 3
M10 $0.2658+1 $0.2052+1 $0.2345+1 $0.5730 $0.3738 $0.4383 $0.1644+1 $0.2971+1 $0.7216 $0.3389 $0.1644 $0.4052 $0.1729+1 $0.5003 $0.1891 $0.6571
M12 $0.4343 $0.3539 $0.3923 $0.8616 $0.5786 $0.6860 $0.4877 $1.0554 $0.5318 $0.6290 $0.3864 $0.7546 $0.9585
M8 $0.1564+1 $0.1220+1 $0.1407+1 $0.3777 $0.2455 $0.2839 $0.0935 $0.0985+1 $0.0805 $0.0869+1 $0.1642+1 $0.4680 $0.2212 $0.1050 $0.2664 $0.1095+1 $0.3256 $0.1243 $0.4230
M3 $0.0277 $0.0203 $0.0241 $0.0085+1 $0.0418 $0.0123 $0.0142+1 $0.0098+1 $0.0109+1 $0.0087+1 $0.0084+1 $0.0083+1 $0.0319 $0.0362 $0.0150 $0.0159+1 $0.0175
M6 $0.0829+1 $0.0657+1 $0.0751+1 $0.1996 $0.1243 $0.1486 $0.0447 $0.0488+1 $0.0366+1 $0.0394+1 $0.0386 $0.1016 $0.2496 $0.1124 $0.0523 $0.1319 $0.0550+1 $0.1745 $0.0608 $0.2245
M2.5 $0.0181 $0.0213 $0.0080 $0.0106 $0.0115 $0.0089 $0.0096 $0.0085 $0.0080 $0.0080 $0.0128 $0.0149 $0.0158 $0.0095
M5 $0.0599 $0.0430+1 $0.0527+1 $0.1365 $0.0843 $0.1026 $0.0266 $0.0303+1 $0.0232+1 $0.0253+1 $0.0213+1 $0.0214 $0.0684 $0.1684 $0.0766 $0.0329 $0.0941 $0.0369+1 $0.1191 $0.0393 $0.1535
M4 $0.0406 $0.0306+1 $0.0352 $0.0888 $0.0598 $0.0675 $0.0195 $0.0217+1 $0.0157+1 $0.0172+1 $0.0144+1 $0.0147+1 $0.0145 $0.0439 $0.0486 $0.0238 $0.0656 $0.0253+1 $0.0766 $0.0276
M2 $0.0080 $0.0092 $0.0101 $0.0080 $0.0083 $0.0080 $0.0080 $0.0080 $0.0115 $0.0128 $0.0080
M1.6 $0.0091 $0.0127 $0.0144 $0.0109 $0.0116 $0.0099 $0.0091 $0.0091 $0.0091
M1.4 $0.0110 $0.0110 $0.0110 $0.0110 $0.0110 $0.0110
Lines in stock under GB 2673
Product Diameter × Length Unit price
GB 2673 Torx Countersunk Screw Full Thread M1.4x3 304 Stainless Steel M1.4 × 3 $0.0110
GB 2673 Torx Countersunk Screw Full Thread M1.4x4 304 Stainless Steel M1.4 × 4 $0.0110
GB 2673 Torx Countersunk Screw Full Thread M1.4x5 304 Stainless Steel M1.4 × 5 $0.0110
GB 2673 Torx Countersunk Screw Full Thread M1.4x6 304 Stainless Steel M1.4 × 6 $0.0110
GB 2673 Torx Countersunk Screw Full Thread M1.4x8 304 Stainless Steel M1.4 × 8 $0.0110
GB 2673 Torx Countersunk Screw Full Thread M1.4x10 304 Stainless Steel M1.4 × 10 $0.0110
GB 2673 Torx Countersunk Screw Full Thread M1.6x3 304 Stainless Steel M1.6 × 3 $0.0091
GB 2673 Torx Countersunk Screw Full Thread M1.6x4 304 Stainless Steel M1.6 × 4 $0.0091
GB 2673 Torx Countersunk Screw Full Thread M1.6x5 304 Stainless Steel M1.6 × 5 $0.0091
GB 2673 Torx Countersunk Screw Full Thread M1.6x6 304 Stainless Steel M1.6 × 6 $0.0091
GB 2673 Torx Countersunk Screw Full Thread M1.6x8 304 Stainless Steel M1.6 × 8 $0.0099
GB 2673 Torx Countersunk Screw Full Thread M1.6x10 304 Stainless Steel M1.6 × 10 $0.0109
GB 2673 Torx Countersunk Screw Full Thread M1.6x12 304 Stainless Steel M1.6 × 12 $0.0116
GB 2673 Torx Countersunk Screw Full Thread M1.6x14 304 Stainless Steel M1.6 × 14 $0.0127
GB 2673 Torx Countersunk Screw Full Thread M1.6x16 304 Stainless Steel M1.6 × 16 $0.0144
GB 2673 Torx Countersunk Screw Full Thread M2x3 304 Stainless Steel M2 × 3 $0.0080
GB 2673 Torx Countersunk Screw Full Thread M2x4 304 Stainless Steel M2 × 4 $0.0080
GB 2673 Torx Countersunk Screw Full Thread M4x5 304 Stainless Steel M4 × 5 $0.0145
GB 2673 Torx Countersunk Screw Full Thread M5x100 304 Stainless Steel M5 × 100 $0.1684
GB 2673 Torx Countersunk Screw Full Thread M2x5 304 Stainless Steel M2 × 5 $0.0080
GB 2673 Torx Countersunk Screw Full Thread M4x6 304 Stainless Steel M4 × 6 $0.0147
GB 2673 Torx Countersunk Screw Full Thread M6x8 304 Stainless Steel M6 × 8 $0.0386
GB 2673 Torx Countersunk Screw Full Thread M2x6 304 Stainless Steel M2 × 6 $0.0080
GB 2673 Torx Countersunk Screw Full Thread M4x8 304 Stainless Steel M4 × 8 $0.0144
